Model / 型號
|
NPN D.on
|
OAP-4004-NK
|
OAP-4004S-NK
|
OAP-4008-NK
|
OAP-4008S-NK
|
|
PNP D.on
|
OAP-4004-PK
|
OAP-4004S-PK
|
OAP-4008-PK
|
OAP-4008S-PK
|
|
Sensing type / 檢出方式
|
Through beam / 對照式
|
|
Resolution / 分辨率
|
60 mm opaque object 不透明物體
|
|
Sensing distance / 檢出距離
|
0.1 M ～ 5 M
|
0.1 M ～ 2 M
|
0.2 M ～ 5 M
|
0.2 M ～ 2 M
|
|
Sensing Height / 檢測高度
|
120 mm
|
280 mm
|
|
Emitting light / 發光源
|
Infrared LED(紅外線發光LED)：850 nm
|
|
No.of Beams/光軸數
|
4
|
8
|
|
Beam pitch / 光軸間距
|
40 mm
|
|
Indicating LED / LED指示燈
|
5 LEDs each on emitter and receiver.
|
7LEDs each on emitter and receiver.
|
|
LEDs blink from top to bottom under the normal emission. All LEDs light up under the emitting circuit failure and will become blinking until the normal emission.
|
|
Running type / 運轉方式
|
More than a beam is covered ON﹙Dark On﹚
任意一個光束被遮斷即輸出
|
|
Operating voltage / 工作電壓
|
DC12 ~ 24 V±10% (ripple P-P：10% Max.)
|
|
Current Consumption / 消耗電流
|
Transmitter：30 mA Max.
|
Transmitter：60 mA Max.
|
|
Receiver：15 mA Max.
|
Receiver：30 mA Max.
|
|
Load current / 負載電流
|
100 mA Max at DC 24V
|
|
Protection circuit / 保護電路
|
Reversed Supply circuit protection, Short circuit protection output
電源反接保護及輸出短路保護
|
|
Response time / 反應時間
|
Off to On：15 ms Max.
|
|
On to Off：20 ms Max.
|
|
Insulation resistance / 隔離阻抗
|
20MΩ min. (DC500V)
|
|
Voltage withstandabiligy / 絕緣耐壓
|
AC1000V 60Hz for 60 Sec.
|
|
Operating temperature/工作溫度
|
- 10 ℃ ~ + 45℃ ﹙No freezing allowed不可結霜,結冰﹚
|
|
Ambient humidity / 工作濕度
|
35% ~ 85% RH 相對濕度
|
|
Storage temperature / 儲存時溫度
|
- 10 ℃ ~ + 45℃ ﹙No freezing allowed不可結霜,結冰﹚
|
|
Storage humidity / 儲存時濕度
|
35% ~ 95% RH 相對濕度
|
|
Protection degree / 防水等級
|
IP62
|
|
Material / 外觀材質
|
ABS
|
|
Wiring method / 出線方式
|
Transmitter：M12 pigtailed type(5P) / M12接頭15cm電線式
|
|
Receiver：M12 pigtailed type(5P) / M12接頭15cm電線式
|
|
Weight /重量
|
Approx.200g
|
Approx.253g
|
