Model/型號
|
OAS2608D
|
OAS2616D
|
OAS2624D
|
OAS2632D
|
OAS2640D
|
|
NO. of beams / 光束數
|
8
|
16
|
24
|
32
|
40
|
|
Detecting height / 檢測高度
|
188
|
390
|
598
|
806
|
1,014
|
|
Beam Pitch / 光束間距
|
26mm
|
|
Detecting Range / 檢驗距離
|
0.3m to 4m
|
|
Resolution / 分辨率
|
30㎜ opaque object 不透明物體
|
|
Supplying voltage / 供應電壓
|
DC 10V to 24V ± 10%(ripple P-P:10% Max.)
|
|
Current consumption
/電流消耗量
|
65mA Max.
|
70mA Max.
|
75mA Max.
|
80mA Max.
|
85mA Max.
|
|
Electro-characteristics
/電氣特性
|
NPN open collector開放集極電路, Load current 負載電流: Max. 200mA
(Max. DC30V) Remaining voltage 剩留電壓: 200mA ~ Max. 2V
|
|
Response time / 反應時間
|
Max. 20ms
|
|
Indicating LED / LED 指示燈
|
■ Emitter發射機 ------- Power : Red LED
■ Receiver 接收器 ----- Power : Red LED
Detecting 檢測 : Red LED
Stable status 穩定狀態 : Red LED
|
|
Light source / 光源
|
Infrared radiation diode 紅外線發光LED(λ = 870nm)
|
|
Running type / 運轉方式
|
More than a beam is covered ON (Light ON)遮斷涵蓋一光束以上
|
|
Protection circuit / 保護電流
|
Reversed Supply circuit protection, Short circuit protection output
逆電流保護，短路保護輸出
|
|
Connection / 連接
|
300㎜ connector mount cable連接插頭固定線
|
|
Temperature / 溫度
|
When Running 運轉時:-10℃ ~ +55℃ (shouldn't be any condensation or frost) 不可有任何的凝結或結霜When keeping 保留時: -10℃ ~ +60℃
|
|
Humidity / 濕度
|
When running 運轉時: within 35% ~ 85%RH 相對濕度,
When keeping 保留時: within 35% ~ 95%RH 相對濕度
|
|
Ambient light / 周圍光線
|
Sun light 日光 : Max.10000lx
Ambient light 周圍光線:Max. 3000lx
|
|
Insulation resistance / 絕緣阻抗
|
20MΩ min.(At DC500V)
|
|
Anti-voltage / 逆電壓
|
AC1000V 50/60Hz for 60sec
|
|
International protection
/國際防水等級
|
IP64 (IEC)
|
|
Anti-vibration / 反震動
|
1.5mm amplitude 振幅 2Hr, 3 directions each各自3方向
|
|
Anti-shock / 反電沖
|
100 m/2s X, Y, Z 2 hours each directions每方向2小時
|
|
Material / 材質
|
Case 外殼: Aluminum 鋁, Side cover 側蓋: Zinc 鋅, Lens cover 鏡頭蓋: Acryl壓克力
|
|
Weight / 重量
|
Approx.370g
|
Approx.610g
|
Approx.840g
|
Approx.1,080g
|
Approx.1,320g
|
|
Optional Cable / 可選擇線長
|
5M length 長度
|
